Product Description
The 15BBL Brewhouse Equipment complete SUS304 direct fire heating two vessel brewhouse is often used in microbreweries. The system contains three brewhouse vessels, a mash tun/lauter tun and a boiling/whirlpool tun. The mashing process and the wort filtration process are completed by Mash tun/ lauter tank; The boiling and whirlpool processes are completed by one tank.
The system also needs to be equipped with a complete automatic or manual control system, malt milling system, CIP system, cooling system, steam heating system, air system, etc.
Product Parameter
crushing system
| 1. Malt Crusher : Crushing output: 300kg/h ; 2. Crushing effect : the skin is broken but not broken, the roller type; the motor, pulley and belt are matched; 3. Motor power : 1.1kW
|
saccharification system
| 1. Saccharification pot + filtration + boiling + spin sink + hot water tank : ① Dimensions: φ1360×2500; Total volume 1400L, effective volume 1000L; Dimensions of hot water tank: φ1560×2320; Total volume 2200L, effective volume 2000L; ②Saccharification pot: heat exchange area 1.46m2 + boiling : heat exchange area 1.5m2 + hot water tank: heat exchange area 1.6m2 ③The thickness of the insulation layer is 80mm; the thickness of the inner tank is 3mm, and the outer shell is 2mm oil-grinding wire drawing board; 2. Saccharification wort pump : ①Wort or mash conveying capacity: 3m 3 /h; ②Stainless steel sanitary conveying pump, voltage power: 380V, 0.75kW , frequency conversion speed regulation; ③Head : 18m; 3. Plate heat exchanger : heat exchange area: 12㎡; double-section 6-lead, external dimension: 620×320×710 ;
|
Fermentation system
| 1. Beer fermentation tank : ①Dimensions: φ1260×2520; total volume 1320L, effective volume 1000L; ②The thickness of the insulation layer is 80mm ; the thickness of the inner tank: 2.5mm ; ③The inner tank is mechanically polished, outsourced with 2mm oil-grinding wire drawing board, and the welded seam is polished and sanded; ④Heat exchange area: 2.2m 2 2. Wort oxygenation device : It is made of 304 stainless steel finishing, no pollution dead angle, with titanium rod and sight glass, oxygenation can be seen evenly; 3. Fermentation pipeline and valve : food-grade stainless steel pipeline, argon arc welding inner protection welding without pollution dead angle, high-quality sanitary butterfly valve.
|
Cooling System
| 1. Ice water tank : Dimensions: φ1800×2330; total volume 3200L, effective volume 3000L; 2. Refrigeration unit : Air-cooled unit Refrigeration capacity: 8HP, power: 6kW/group 3. Ice water pump : flow rate 4m 3 /h lift 36m; centrifugal 220V 0.75kw to heat exchanger and fermentation tank to cool down
|
Control System
| Control cabinet : Dimensions: 1700×700×350mm ; realize the temperature display of saccharification system, automatic temperature control of fermentation system, power control, and automatic temperature control of ice water;
|
cleaning system
| CIP cleaning truck : Dimensions: φ1300×600 Effective volume: 100L, including 100L lye tank, sterilization tank and trolley; inner tank thickness: 2mm; outer surface oil-grinding wire drawing board, welding seam polishing belt
|
| Remark | For details, please contact the company’s business personnel, and enter into detailed communication and negotiation. |
| Beer Brewing Equipment | |
| Company introducation | We Kuangbo is a production enterprise of pharmaceutical, dairy, food and beer-making equipment, alongside biological engineering, chemical containers, and bespoke products. Our products are widely used in beer production, pharmaceuticals, beverage industries, biotechnology and other fields. |
| Usage | it is used for beer Brewing |
| Material | 1.SUS304, 316L |
| 2.jacket: dimple jacket | |
| 3.insulation layer: PU | |
| 4.as to the thickness, we can make it according to your requirement. | |
| Configuration | safty valve, CIP spraying ball and pipe at the side of the tank, outlet with valve and racking arm as your requirement, temperature gauge and sample valve |
| Our advantage | 1.we can supply various kinds of volume, minimum 50L, maximun 30,000L and even larger. |
| 2.PU insulation is adopted, jacket will be dimple jacket | |
| 3.interior surface is 3A finish and exterior is 2B finish | |
| 4.we also can equip you with a cooling system as your requirement. | |
| 5.competitive price and also higher quality tank. | |
| Minimum order | one unit |
| Payment term | T/T or L/C |
| Package | export standard package |
| Market | at home and abroad |
| Beer Brewing System List | ||
| Milling System | 1 | Malt miller |
| Saccharification System | 1 | Mash tun |
| 2 | Boil kettle | |
| 3 | Wort pump | |
| 4 | Plate heat exchanger | |
| 5 | Saccharification pipelines and valves | |
| Fermentation System | 1 | Fermentation tank |
| 2 | Fermentation pipelines and valves | |
| 3 | Yeast adding tank | |
| Refrigeration System | 1 | Glycol ice water tank |
| 2 | Refrigerating Unit | |
| 3 | Ice water circulating pump | |
| 4 | Ice water pipelines and valves | |
| CIP System | 1 | Washing pump |
| 2 | Alkali tank | |
| 3 | Sterilization tank | |
| Control System | 1 | Saccharification Control |
| 2 | Fermentation Control | |
| 3 | Refrigeration Control | |
| 4 | CIP Control | |
| Filter System | 1 | Kieselguhr filter machine |
| 2 | Bright beer tank | |
| Capacity | Cylinder(ODxH) | OAH | Inner Thickness |
| 7BBL | 1000 x 1250mm | 2530mm | 3mm |
| 10BBL | 1150 x 1250mm | 2670mm | 3mm |
| 15BBL | 1250 x 1680mm | 3250mm | 3mm |
| 20BBL | 1400 x 1700mm | 3400mm | 3mm |
| 30BBL | 1650 x 1850mm | 3740mm | 3mm |
| 40BBL | 1750 x 2050mm | 4040mm | 3mm |
| 50BBL | 1750 x 2750mm | 4770mm | 3mm |
| 60BBL | 1150 x 1250mm | 2670mm | 3mm |
| 80BBL | 2100 x 2900mm | 5300mm | 3mm |
| 100BBL | 2200 x 3350mm | 5850mm | 3mm |
Product Advantage
Key features:
Built with AISI 304 stainless steel
5-year limited manufacturer’s warranty
Dished head and conical bottom
Insulated with Polyurethane foam
Double-acting air vent valve (below 100HL)
Pressure and anti-vacuum valve (100HL and above)
CIP with spray ball and blow-off arms
Temp, sensor, sample valve, and butterfly valves
Shadowless manway
2″ bottom drain outlet
6″ hop port
Rotating racking arm
Our Service
Vdobrew brewery equipment series are used in the construction of breweries. The company adopts professional factory systematic brewing procedures, and can install and debug equipment and collect and purchase raw materials according to your requirements.
Such equipment generally has a volume of 1000 liters, 2000 liters, 3000 liters, 5000 liters and more than 5000 liters.
Brewery equipment composition: crushing system, saccharification system, fermentation system, cold water system, ice water system, cleaning system, filtration system, filling system, sterilization system, etc.
(1) Brewery equipment configuration:
| Specifications/ginsengnumber | 1000L | 2000L | 3000L | 5000L |
| production capacityforce | 1000L/day | 2000L/day | 3 000L/day | 5 000L/day |
| combinationsquareMode | Three-organ three- body saccharification system, four-organ four-body saccharification system, five-organ and five-body saccharification system | |||
| Electric three- phase | Three-phase electricity / 380(220, 415,440…)v / 50 (60)Hz | |||
| heating method | Electric heating / steam heating / direct fire heating | |||
| inner layer | The inner and outer walls of the barrel stainless steel 304 original plate are finely polished by argon arc welding | |||
| outer cladding | Cylinder stainless steel 304 original plate/mirror panel argon arc welding inner and outer wall fine polishing | |||
| floor space | >200 square meters | >300 square meters | >500 square meters | Determined by craftsmanship and investment |
| price | 220,000-300,000 | 450,000-600,000 | Inquire | Inquire |
| Remark | The configuration here is for reference only, the specific configuration and price need to be determined according to your specific situation, you can consult customer service! | |||
(2) Combination form of brewery equipment :
Small beer production plants produced by Vdobrew produce batches from 300 liters to 5,000 liters.
At the same time, we provide corresponding services, such as a complete set of small beer equipment, full installation services, brewing recipes and processes of well-known wine varieties, and so on.
We can provide turnkey projects for beer equipment.
If you want to know more about the equipment of the brewery, you can consult the Vdobrew team, we will give you a satisfactory configuration plan!
